    Does anyone know if ASP or TCSS parts will fit onto flash handles?

  5. SethS

    SethS Master Member RPF PREMIUM MEMBER

    Trophy Points:
    2,791
    With some trickery, yes. Can you just pop them on? No.

    I have several sabers in these pages that use both.

  6. connor645

    connor645 New Member

    Trophy Points:
    3
    Right on, what sort of trickery have you used in the past?

  7. SethS

    SethS Master Member RPF PREMIUM MEMBER

    Trophy Points:
    2,791
    Here's a few I have been meaning to share...

    This one is based on a Presslite flash. The lower 3/4 is the Presslite, I've just reconfigured the stock parts. I also added t-track, and a Roman's Graflex repro clamp with a TCSS edge card.

    The neck/emitter is a TCSS pommel. I used plumber's silicone tape on the threads until it was the perfect thickness to tension fit inside the flash tube. The emitter/shroud is from a Canon Y, and is affixed with epoxy.

    press2.jpg press3.jpg

    This stealthy saber is (from top down), some rando eBay bad Luke V2 repro emitter and neck, an end cap from an underwater Nikon flashgun with some washers, a 1/4 camera tripod lock washer, a screen door roller wheel, an old Parks MPP clamp, then a TCSS body, TCSS pommel, another roller wheel, and a nylon lock nut.

    This one is built using the Obi-Wan method, everything is on a 1/4" 20 pitch rod. You can get them at any hardware store. 1/4" 20 is great, there are tons of common hard ware parts that use it that you can use for greeblie details, and it also is what most camera equipment uses for tripod mounts, which is universal to most flashguns.

    So that nylon twist knob nut thinger at the bottom is the base of the rod, and inside the emitter is another 1/4" nut. You put everything on the rod and tighten both ends and everything is pressure locked unto place.


    This one also uses a rod assembly. Top down, it's a Heiland stubby shroud on a neck made up of rando hardware plumbing department finds, then a trio of roller door wheels. The lower body is a TCCS f to f coupler and one of their blade holders/emitters that I used upside down. The pommel is a plastic chromed AS handwheel. The d-ring is a 1/4" tripod knob.


    So basically, starting at the bottom, I use that tripod d-ring through the handwheel. On the inside of the wheel, I use an f to f 1/4" 20 adapter (see below). The tripod knob into one side, the rod into the other.

    From there I start stacking the parts over the rod. They will be loose and drift at first. Sometimes using washers between parts helps. The roller wheels work as washers and also look great.

    At the top, I slipped a part from a hard drive over the rid and tightened it down with two of the nylon nuts to make the emitter.

    Hope that makes sense. It's a great base to build on. See my box below that;'s full of 1/4" 20 parts. All hardware store finds, greeblies found off old flashguns or photogear surplus, and Home Depot finds It's also pretty easy to drill a hole down the center of the guts in most flashed to run a rod through.
