Ronon Dex Particle Magnum

Discussion in 'Replica Props' started by MolochSim, May 12, 2015.

  1. MolochSim

    MolochSim New Member

    Trophy Points:
    2
    Hi everyone. I have been lurking on here for quite some time and this is my first post.

    I am working on a replica of the Particle Magnum blaster used by Ronon Dex in Stargate: Atlantis. It will be made mostly from foam and thin plastic sheets. I hope to post some progress soon. I took my time working on the blueprints, trying to get them very accurate, because I couldn't find any online.

    So, I am looking for a bit of advice on how to make the indentations on the front of the blaster. I was thinking of making a straight recess and then filling in the endings using some kind of filler to shape the endings. This seems like a lot of work and any mistake would probably mean starting over on the part. Does anyone have an idea on how to do this differently? Thanks, I would appreciate any help and input. :)


  2. Alric

    Alric Well-Known Member

    Trophy Points:
    867
    A router bit would do it all for you.

  3. MolochSim

    MolochSim New Member

    Trophy Points:
    2
    Thank you, I never used those bits before, but I will give it a shot. It might be tricky to find one that is similar enough in size to use. Though I guess if it is smaller, I could do it in a few passes and it should turn out ok.

  4. chevron

    chevron Active Member

    Trophy Points:
    242
    Very interested in seeing how this turns out! Good luck!

    Last edited: Jun 8, 2015
  5. MolochSim

    MolochSim New Member

    Trophy Points:
    2
    Thanks, I am currently working on the main body and I will have some photos to post later this week, hopefully. :)
    I have considered it. I will see how it turns out first and maybe work on refining it before I think about molding it.

  6. MolochSim

    MolochSim New Member

    Trophy Points:
    2
    So, I am posting two photos taken last week. I had a bit of a problem with the pvc pipe curving slightly, but I mostly fixed it. Now I am doing details on the main body, such as the sloping sides from the thicker area above the trigger. Once that is done, I will do another layer or two of resin and make the inside cutouts for the wiring and LEDs. The grip sides have now been primed and I will post them as soon as they are painted. :)

    Last edited: Jun 8, 2015
  7. chevron

    chevron Active Member

    Trophy Points:
    242
    The pics don't work.

  8. clarence

    clarence Well-Known Member

    Trophy Points:
    746
    Hi! When You have marked out the slots ,using the correct sized drill bit make a hole each end of the slot and then cut two straight lines to connect them. This will save using a router.There used to be a kit for that weapon on E-Bay.

  9. Badwolf234

    Badwolf234 Active Member

    Trophy Points:
    460
    Hey I've been working on a full aluminium particle magnum with full working lights and wondering if anyone would be interested in them to my knowledge there are only 2 of them in the world one own by Jason himself and the second by a nice guy who bought the second one I have finished my own one so now I own the third and thinking of selling them and wanted to get the thought of some people if there is interest I can post some photos soon

  10. chevron

    chevron Active Member

    Trophy Points:
    242
    I'd like photos.

  11. nomuse

    nomuse Sr Member RPF PREMIUM MEMBER

    Trophy Points:
    1,035
    I'd love to see pics too. Of either project!

  12. Badwolf234

    Badwolf234 Active Member

    Trophy Points:
    460
    hey alright this photo is from a couple of days ago the handle on this is not the final handle just one so you can see how it will all fit and the head is a resin one from the resin replica there is no electronics yet plan to do them tomorrow.it will be constructed the same as the original prop to halves held by small hex screws on the other side the paint job on this sis amazing but sadly dosnt show that well in photos but you get the idea the trigger has been done in the photo it was still rough ill try get some better photos soon IMG_2945.JPG

  13. Badwolf234

    Badwolf234 Active Member

    Trophy Points:
    460
    IMG_3021.JPG IMG_3022.JPG IMG_3022.JPG IMG_3022.JPG IMG_3022.JPG


    Attached Files:

    Last edited: Jul 5, 2015
  14. ArtimusX

    ArtimusX New Member

    Trophy Points:
    2
    Badwolf234 , ah sweet! I am definitely interested. I sent you a PM for a price :D


    MolochSim, I am curious to see how your project's progress is going

  15. Badwolf234

    Badwolf234 Active Member

    Trophy Points:
    460
    Hey guys so I've ran into abit of trouble I'm starting with electronics in my blaster and I want to have a master switch , 3 switches to control 3 different coloured led green red yellow and the I want a fourth led in the cell and 3 laser diodes connected to a pressure switch on The trigger and all connected to a power suppl in the handle here is a little diagram

  16. Badwolf234

    Badwolf234 Active Member

    Trophy Points:
    460
  17. chevron

    chevron Active Member

    Trophy Points:
    242
  18. Badwolf234

    Badwolf234 Active Member

    Trophy Points:
    460
    I saw that I actually sent a email I'm interested in the electronics if you'd are willing to sell some of the components I'm actually planning on doing a complete version on the mill and I wanted some electronics on the one I've made the chamber removes and powers up but I'm very interested in sound and what not
