Millenium Falcon prop guns

Discussion in 'General Modeling' started by CrazyCraig, Mar 30, 2015.

  1. CrazyCraig

    CrazyCraig Member

    Trophy Points:
    162
    Decided to start this new thread so not to clog up Starkiller's Difinitive Falcon Interior thread. http://www.therpf.com/f11/definitive-anh-falcon-interior-227052/index5.htmlBut he started this topic anyway. This image is the latest incarnation of prop guns, for anybody interested. Recently started looking at Bluray stills and you can get so much more detail there. If any body knows of a good program for taking screen-caps of Bluray I'd like to know.[​IMG]

  2. vectorzero

    vectorzero Well-Known Member RPF PREMIUM MEMBER

    Trophy Points:
    735
    DVDfab is a great tool

  3. Jedi Dade

    Jedi Dade Sr Member

    Trophy Points:
    1,730
    You need to consider that the full size set guns are a good deal different from the guns on the model. if you're trying to replicate the model there is a TON of great reference on the Falcon models on the internet... but also realize that the 5 foot and 32" falcons are different too... so you need to kind of pick which gun you want to replicate.

    If you're going with the set - the Blu rays are the way to go... there is little reference that I've seen on the as built set guns...

    Good Luck!

    Jedi Dade

  4. CrazyCraig

    CrazyCraig Member

    Trophy Points:
    162
    Thanks vectorzero, I'll look it up.

  5. CrazyCraig

    CrazyCraig Member

    Trophy Points:
    162
    Thanks Jedi Dade. It's because there is little info on the set prop guns that I'm posting these images. These guns are the ones I'm going to use.

  6. CrazyCraig

    CrazyCraig Member

    Trophy Points:
    162
    Here is the latest revision of the set-guns. Cables and tubing omited for clarity.
    [​IMG]

  7. SofaKing01

    SofaKing01 Master Member

    Trophy Points:
    3,660
    NICE! I might have to recreate the full scale version I have! Thanks a lot!

    ;)

  8. CrazyCraig

    CrazyCraig Member

    Trophy Points:
    162
    I have a theory about the reason the guns were built this way. Apologies if it's been mentioned before in this forum - I'm new. I've always wondered what was going on with the center-post on the prop.With in-universe practicality, it wouldn't work. I think I know why. The center-post (highlighted in orange) of the prop seems to go all the way down to the surface of the gun. The sketch designs don't. The gun couldn't pivot if it did. The reason I think this is for a lever and pivot to pass down the center-post so the gun can be pivoted up and down. Comparing the sketches with the set they appear to have moved a 'electronics box' from the end of the center-post to the back of the gun to hide this. This set-up, to me, justifies the way its made. Any opinions?

    Another thing. Highlighted on the plan is a circular greeblie peice of the prop. That looks like the cap from a 44 Gallon oil drum, or something similar. My parents ran a service station (gas) when I was a kid and I realised that thing looked familiar.


    [​IMG]

    Last edited: Apr 3, 2015
  9. SteveStarkiller

    SteveStarkiller Sr Member

    Trophy Points:
    1,730
    [​IMG]

    this is what I got, by the way, photomatching images of the actual prop.


    Attached Files:

  10. CrazyCraig

    CrazyCraig Member

    Trophy Points:
    162
    Thanks for the image Starkiller. I was about to ask you to explain how photomatching works due to the shorter dimentions than the model. But last week I did some more Google-searching and found this image http://http://sphotos-h.ak.fbcdn.net/hphotos-ak-snc7/464104_550363141657668_1593085567_o.jpg of the Hope Falcon with the prop guns on top. After looking again at it closer and see you seem to be pretty right. So I'm off to do a shortened version of my diagram.

    Last edited: Apr 20, 2015
  11. CrazyCraig

    CrazyCraig Member

    Trophy Points:
    162
    Here is the latest revision based on SteveStarkiller's photomatch. With this it looks like we are getting close to the prop. [​IMG][/URL][/IMG]

    KramStaar likes this.
  12. CrazyCraig

    CrazyCraig Member

    Trophy Points:
    162
    Found my first pic of the TFA Falcon guns the other day, so I thought I'd put up a a qick plan.
    So for anyone who doesn't have an idea of what they look like these days here's one example.[​IMG]

  13. CrazyCraig

    CrazyCraig Member

    Trophy Points:
    162
    I've had a long time off the Falcon, so to get back in the swing I decided to make a model of the Falcon's guns. It will give an idea how accurate the plan is. It is crude and simply made out of cardboard, paper and eight toothpicks. [​IMG]

  14. CrazyCraig

    CrazyCraig Member

    Trophy Points:
    162
    Also, I don't have a functioning printer at the moment so I drew a rough plan off the screen with dividers. There are proportional errors here and there due to that. This doesn't matter becuse this was just to show how well the plan works in three dimensions.[​IMG]

    - - - Updated - - -

    I tried to get some photos from similar angles to the moves so you can compare.[​IMG]

  15. CrazyCraig

    CrazyCraig Member

    Trophy Points:
    162
  16. TazMan2000

    TazMan2000 Sr Member

    Trophy Points:
    1,730
    Extremely cool.

    TazMan2000
