Incom T-65 Screen Accurate ANH Cockpit in 3D to Print for Studio Scale |Build Thread

[Gus76]

Re: Incom T-65 Screen Accurate ANH Cockpit in 3D to Print for Studio Scale |Build Thr

Thank you everyone for the comments! More updates. The design is finished. I am waiting for the clear resin to arrive, so I can start production. I will create a project run thread soon. For now please check out the latest work in progress photos:

The non-primed parts on the next photos will be printed in clear resin:



[craig g]

Re: Incom T-65 Screen Accurate ANH Cockpit in 3D to Print for Studio Scale |Build Thr

That is something very special.
Awesome job!!!



[CAPTAINCOX]

Re: Incom T-65 Screen Accurate ANH Cockpit in 3D to Print for Studio Scale |Build Thr

Brilliant and awesome work there!.Just love your attention to Detail and the amount of Hours you probably spent checking Refference material...simply brilliant!
If you are planning to do a Resin Kit I am 100% in for it .



[Army]

Re: Incom T-65 Screen Accurate ANH Cockpit in 3D to Print for Studio Scale |Build Thr

This is amazing, the detail you put into this is nothing short of perfection.


chris



[Gans]

Re: Incom T-65 Screen Accurate ANH Cockpit in 3D to Print for Studio Scale |Build Thr

Wow.................so does it fit it the studio scale kits now?????



[Waketrail]

Re: Incom T-65 Screen Accurate ANH Cockpit in 3D to Print for Studio Scale |Build Thr

That's some awesome work.
I am curious; what software package are you using for the design work? Looks like you are have great results with it.



[stonky]

Re: Incom T-65 Screen Accurate ANH Cockpit in 3D to Print for Studio Scale |Build Thr

This really is incredible. :thumbsup



[Gus76]

Re: Incom T-65 Screen Accurate ANH Cockpit in 3D to Print for Studio Scale |Build Thr

Thank you so much everyone for the kind words. I do plan to release it as a kit, but SLA printed. If done in resin, a lot of details will have to be sacrificed.

Here is a rough fitment with the top part of the hull. This is v.4 Salzo kit. I haven't really done anything to it yet other than cleaning up the windows a bit.

Brilliant and awesome work there!.Just love your attention to Detail and the amount of Hours you probably spent checking Refference material...simply brilliant!
If you are planning to do a Resin Kit I am 100% in for it .



[Gus76]

Re: Incom T-65 Screen Accurate ANH Cockpit in 3D to Print for Studio Scale |Build Thr

More photos with better fitment and clear parts



[Enhancer4004]

Re: Incom T-65 Screen Accurate ANH Cockpit in 3D to Print for Studio Scale |Build Thr

Wow that looks simply unbelievable. Great job!



[Gus76]

Re: Incom T-65 Screen Accurate ANH Cockpit in 3D to Print for Studio Scale |Build Thr

I have created a project run thread located here:
http://www.therpf.com/showthread.php?t=263001



[joberg]

Re: Incom T-65 Screen Accurate ANH Cockpit in 3D to Print for Studio Scale |Build Thr

Very cool cockpit details! It's going to be a must for anyone building that bird at that scale!



[danikin72]

Re: Incom T-65 Screen Accurate ANH Cockpit in 3D to Print for Studio Scale |Build Thr

Are you able to scale it up to the big hero x-wing...i think its like 1/18 or close.
Would love to buy a cockpit off ya.



[Dogsbody]

Re: Incom T-65 Screen Accurate ANH Cockpit in 3D to Print for Studio Scale |Build Thr

Those coaming angles are a PITA in 3D..The three quadrants on the coaming edge I think are aircraft controls.Lovely work and Ill have a set for my Hasbro one I started one ages ago but got nowhere..



[Gus76]

Re: Incom T-65 Screen Accurate ANH Cockpit in 3D to Print for Studio Scale |Build Thr

Version of the cockpit for 1/29 Revell kit:
As usual, some cutting, sanding and fitting is required to fit in the cockpit. The clear parts are not shown but will be included.

Thank you for looking.



[Jaitea]

Re: Incom T-65 Screen Accurate ANH Cockpit in 3D to Print for Studio Scale |Build Thr

Incredible....I've seen the future!!

J



[joberg]

Re: Incom T-65 Screen Accurate ANH Cockpit in 3D to Print for Studio Scale |Build Thr

That kit now looks like hell compared to your super-duper-cockpit:eek



[dtssyst]

Re: Incom T-65 Screen Accurate ANH Cockpit in 3D to Print for Studio Scale |Build Thr

The 1/24 scale cockpits arrived yesterday. Two are for commission builds (Dao2) and one is for me. These are phenomenal !!! If you are on the fence questioning if you should get these, jump down off that fence as fast as you can and place your order. No really, why are you still reading, you should be ordering.

Any corrections, if any, would be easier access from the bottom (like a removable one). This would help greatly in the area of lighting. Otherwise, this is a fantastic addition to the Salzo kit.



[Gus76]

Re: Incom T-65 Screen Accurate ANH Cockpit in 3D to Print for Studio Scale |Build Thr

The 1/24 scale cockpits arrived yesterday. Two are for commission builds (Dao2) and one is for me. These are phenomenal !!! If you are on the fence questioning if you should get these, jump down off that fence as fast as you can and place your order. No really, why are you still reading, you should be ordering.

Any corrections, if any, would be easier access from the bottom (like a removable one). This would help greatly in the area of lighting. Otherwise, this is a fantastic addition to the Salzo kit.

Thank you very much! I am really glad you liked it and I appreciate the comments. What I was thinking is the cockpit has two "walls", external and internal. External essentially serves as a support during printing process, it is not visible after it is installed. So you could possibly trim that external "wall" from the bottom up to the level you are comfortable with. That would provide much better access for installing fiber optics. I hope this helps, but if I miss something, please do let me know. Actually, please let me know in any case [emoji4]



[Gus76]

Re: Incom T-65 Screen Accurate ANH Cockpit in 3D to Print for Studio Scale |Build Thr

Are you able to scale it up to the big hero x-wing...i think its like 1/18 or close.
Would love to buy a cockpit off ya.

Here you go. Scaled to Hasbro Hero 1/18 X-Wing. I ran our of grey primer so had to prime it with white. Sorry for not so perfect cutting job:
