Jackieisrockin's IM3 Iron Patriot Pepakura Files! V2 files coming soon!

Re: Jackieisrockin's Iron Patriot (IM3) Pepakura Files! Links in first post! Neck add

laellee said:
Jackie, just to confirm, the upper torso, lower torso, and neck piece ALL NEED TO BE THE SAME SCALE so that they fit together properly? My understanding is that there is some lee-way with the helmet size, but these other three pieces jigsaw puzzle together and require the same scaling.
The suit looks great so far! :eek
Click to expand...

Yes you are absolutely correct those 3 files MUST be the same scale to fit together properly :)

Re: Jackieisrockin's Iron Patriot (IM3) Pepakura Files! Links in first post! Neck add

yo jackie, mind changing the link for the helmet file?

Iron Patriot Helmet by Jackieisrockin foam template by gaiatron(good scale) V2.pdo - 4shared.com - online file sharing and storage - download

this new one has the right scale that i'm using now and has guides for the details that you can etch incase you propsters dont want a triple piece faceplate.



forgot to post this yesterday. same technique im using for my 2nd helmet

Last edited:
Re: Jackieisrockin's Iron Patriot (IM3) Pepakura Files! Links in first post! Neck add

gaiatron said:
yo jackie, mind changing the link for the helmet file?

Iron Patriot Helmet by Jackieisrockin foam template by gaiatron(good scale) V2.pdo - 4shared.com - online file sharing and storage - download

this new one has the right scale that i'm using now and has guides for the details that you can etch incase you propsters dont want a triple piece faceplate.



forgot to post this yesterday.
Click to expand...

This! :thumbsup

Re: Jackieisrockin's Iron Patriot (IM3) Pepakura Files! Links in first post! Neck add

gaiatron said:
yo jackie, mind changing the link for the helmet file?

Iron Patriot Helmet by Jackieisrockin foam template by gaiatron(good scale) V2.pdo - 4shared.com - online file sharing and storage - download

this new one has the right scale that i'm using now and has guides for the details that you can etch incase you propsters dont want a triple piece faceplate.



forgot to post this yesterday. same technique im using for my 2nd helmet
Click to expand...

Fixed :)

Re: Jackieisrockin's Iron Patriot (IM3) Pepakura Files! Links in first post! Neck add

Nice Job, Jackie.

Did anyone notice in the American Flag photo, IPs LEFT Inner Elbow Armor is BENT?

(Clearly Plastic) - They need to do a better job of spotting that stuff when filming.

Re: Jackieisrockin's Iron Patriot (IM3) Pepakura Files! Links in first post! Neck add

Jackie...this is impossible.

Re: Jackieisrockin's Iron Patriot (IM3) Pepakura Files! Links in first post! Neck add

Haha im sorry Stealth, i just simply had to post that picture ;)

Re: Jackieisrockin's Iron Patriot (IM3) Pepakura Files! Links in first post! Neck add

Poor Stealth is going to have a nervous breakdown lol. So much to make, so little time!

Re: Jackieisrockin's Iron Patriot (IM3) Pepakura Files! Links in first post! Neck add

P4r4dox86 said:
Poor Stealth is going to have a nervous breakdown lol. So much to make, so little time!
Click to expand...
lol
I'll just breathe....and wait for this to be done before I build it.

I need to leave this thread for a LONG time and go back to my Robocop before I lose interest on it for the 3rd time... :unsure

keep up the awesome work Jackie and the guys helping out. :thumbsup

Re: Jackieisrockin's Iron Patriot (IM3) Pepakura Files! Links in first post! Neck add

finished the other helmet. jackie... you're making my heart pump fast!!! will start the upper torso on monday!!!

Re: Jackieisrockin's Iron Patriot (IM3) Pepakura Files! Links in first post! Neck add

gaiatron said:
yo jackie, mind changing the link for the helmet file?

Iron Patriot Helmet by Jackieisrockin foam template by gaiatron(good scale) V2.pdo - 4shared.com - online file sharing and storage - download

this new one has the right scale that i'm using now and has guides for the details that you can etch incase you propsters dont want a triple piece faceplate.



forgot to post this yesterday. same technique im using for my 2nd helmet
Click to expand...

What does this mean- the right scale? Was the first helmey scale off? Thanx GM

Re: Jackieisrockin's Iron Patriot (IM3) Pepakura Files! Links in first post! Neck add

done. BUT i think i done gooped and didnt scale it right because its very bobbly on my head. i understand this helmet gives a wider impression than the im helmets, but im thinking its too big. eye separation widths and face plate dimensions are on par with my im helmet. so im hoping i can tweak the jaw and use dowels to bring the helmet inwards to give it a slimmer look, and just hope it doesnt look like poo on me after ive resined it, etc etc.






Re: Jackieisrockin's Iron Patriot (IM3) Pepakura Files! Links in first post! Neck add

The 'ol Scotch Super Glue and Mountain Dew trick... lol


Looks Great.

Re: Jackieisrockin's Iron Patriot (IM3) Pepakura Files! Links in first post! Neck add

Based on the default scale being for an 6'8.5" person and Jackieisrockin's personal measurements, I came up with some estimations for scaling. I'm not sure how accurate these are as I haven't tested these. I only crunched the numbers in a spreadsheet. Anyway, it should at least give you some reference points to start from. lmk if it helps at all; first time trying this.:facepalm


Height
Centimeters----------Inches-------Scale
145.69 ----------------57.36 --------360.234405
148.14 ----------------58.32 --------362.94267
150.59 ----------------59.29 --------365.650935
153.04 ----------------60.25 --------368.3592
155.48 ----------------61.21 --------371.067465
157.93 ----------------62.18 --------373.77573
160.38 ----------------63.14 --------376.483995
162.83 ----------------64.11 --------379.19226
165.28 ----------------65.07 --------381.900525
167.73 ----------------66.04 --------384.60879
170.18 ----------------67.00 --------387.317055 <-------jackieisrockin
172.63 ----------------67.96 --------390.02532
175.08 ----------------68.93 --------392.733585
177.53 ----------------69.89 --------395.44185
179.98 ----------------70.86 --------398.150115
182.43 ----------------71.82 --------400.85838
184.88 ----------------72.79 --------403.566645
187.33 ----------------73.75 --------406.27491
189.77 ----------------74.71 --------408.983175
192.22 ----------------75.68 --------411.69144
194.67 ----------------76.64 --------414.399705
197.12 ----------------77.61 --------417.10797
199.57 ----------------78.57 --------419.816235
202.02 ----------------79.54 --------422.5245
204.47 ----------------80.50 --------425.232765 <------- default
206.92 ----------------81.46 --------427.94103
211.82 ----------------83.39 --------433.35756
216.72 ----------------85.32 --------438.77409
221.62 ----------------87.25 --------444.19062

Last edited:
Re: Jackieisrockin's Iron Patriot (IM3) Pepakura Files! Links in first post! Neck add

Stealth- Thank you very much! Check back soon! Almost done :)

Gaiatron- Thanks! Good luck on the torso! Post pictures :)!

Torx- Looks great! Cant wait to see it finished :popcorn

Somnambulus- Awesome! Thanks for doing that im sure it will help a LOT of people out :thumbsup

Re: Jackieisrockin's Iron Patriot (IM3) Pepakura Files! Links in first post! Neck add

If you guys are having problems with the scaling then pay attention to this.

If you look in the attributes, Jackie's default "assembled" size is height- 267mm; width- 187; depth- 241. However, that isn't the actual size of the default assembled size, but the size of the "box". Check out the attached pic- Point to Point measurement -"assembled" width is 178.77 and that's the outmost part of the helmet (inside temple to temple is 153.89).

My head is 23 3/4 circumference and I need the inside (temple to temple) with of 165mm. So for me to fit the helmet properly, I had to change the width to 199mm (height-288mm; depth- 260mm)

So Torx, you said your assmebled helmet looked to bobblehead. How did you manipulate your scale/attributes?

Last edited:
Re: Jackieisrockin's Iron Patriot (IM3) Pepakura Files! Links in first post! Neck add

somnambulus said:
Based on the default scale being for an 6'8.5" person and Jackieisrockin's personal measurements, I came up with some estimations for scaling. I'm not sure how accurate these are as I haven't tested these. I only crunched the numbers in a spreadsheet. Anyway, it should at least give you some reference points to start from. lmk if it helps at all; first time trying this.:facepalm


Height
Centimeters----------Inches-------Scale
145.69 ----------------57.36 --------360.234405
148.14 ----------------58.32 --------362.94267
150.59 ----------------59.29 --------365.650935
153.04 ----------------60.25 --------368.3592
155.48 ----------------61.21 --------371.067465
157.93 ----------------62.18 --------373.77573
160.38 ----------------63.14 --------376.483995
162.83 ----------------64.11 --------379.19226
165.28 ----------------65.07 --------381.900525
167.73 ----------------66.04 --------384.60879
170.18 ----------------67.00 --------387.317055 <-------jackieisrockin
172.63 ----------------67.96 --------390.02532
175.08 ----------------68.93 --------392.733585
177.53 ----------------69.89 --------395.44185
179.98 ----------------70.86 --------398.150115
182.43 ----------------71.82 --------400.85838
184.88 ----------------72.79 --------403.566645
187.33 ----------------73.75 --------406.27491
189.77 ----------------74.71 --------408.983175
192.22 ----------------75.68 --------411.69144
194.67 ----------------76.64 --------414.399705
197.12 ----------------77.61 --------417.10797
199.57 ----------------78.57 --------419.816235
202.02 ----------------79.54 --------422.5245
204.47 ----------------80.50 --------425.232765 <------- default
206.92 ----------------81.46 --------427.94103
211.82 ----------------83.39 --------433.35756
216.72 ----------------85.32 --------438.77409
221.62 ----------------87.25 --------444.19062
Click to expand...

I checked those out and it's pretty close, but not the right way to use (assuming this is for the torso).

The 425.232 is the outmost width (green line-check the attached pic). So if you guys want to get the right fit, then you have to consider the size of the lower opening of the upper torso (yellow line) according to the size of the outmost depth of the lower torso. I measured the default depth of the Torso and it's approx. 381mm in depth.

So with Jackie's scale the "inside" mesurements are width-339.63; depth-346.58.

I'm also 5'7" and the inside width that I have to use is 305mm (measured with chest expanded) with the lower torso fitting in it. The scale factor is 379.19226.

Last edited:
Re: Jackieisrockin's Iron Patriot (IM3) Pepakura Files! Links in first post! Neck add

Tigerblood said:
I checked those out and it's pretty close, but not the right way to use (assuming this is for the torso).

The 425.232 is the outmost width (green line-check the attached pic). So if you guys want to get the right fit, then you have to consider the size of the lower opening of the upper torso (yellow line) according to the size of the outmost depth of the lower torso. I measured the default depth of the Torso and it's approx. 381mm in depth.

So with Jackie's scale the "inside" mesurements are width-339.63; depth-346.58.
Click to expand...

I think somnambulus was only measuring by height, as did i for my scale. When i made my Mk VI, i imported the back, chest, abs, and cod and just measured the height and scaled it to me, which worked out just fine, so i did the same thing here
