wow! Pretty amazing layout there Carson!
Thanks for showing the 3d versions of the idea. Seems to prove pretty conclusively that the antenna/push rod head was glued directly on the barrel.
If there was an image of the top view of the Merr Sonn we could know for sure but none have shown up...yet. They still exist don't they? Anybody ever see them at the shows? If so...Get a pic of the top!
I can't see any other way it can be based on the materials we currently have.
As for the Track that Carson questions...
I believe it is as below.
Nothin but Glue...
Note the cross section of the antenna Track. The black area is where the glue would have been.
At the botton you see an example comparison of the HERO and my model with clay acting as glue.
The Glue would have filled the half round hollow under the track as can be seen on the Luke Lightsaber handle(bottom) If you look close you can see the void filled.
The Track is cut or ground at the edge of the hollow.
The glue is also between the antenna and the track edge which creates a "drift" or bevel of glue up the side of the antenna head.
When the gun was fired (probably the first time) the recoil shook the Flash Hider and tipped it into the Track and Left antenna knocking them into oblivion...but that's another movie.
The Right antenna may have been glued just a little further to the rear and did not get dislodged but the Glue from under the Track and along side remained.
The clay and compared top and side images all have the same points and highlights so I believe this is correct. No Track left...only Glue.
Now what the Track looked like when it was on is anybodies guess.
It could have been cut like any of the options at the top in yellow.
Left square like the MerrSonn... but that would have looked silly and blunt and Hans blaster does not have the stuff at the rear to butt the track against.
Could have been cut following a pistol Ramp sight and thee shape of the antenna head... logical
Could have been cut like the Fett Blaster... at a steep bevel
Could have been cut like Luke's Lightsaber handle with a rounded corner...
You can decide which makes sense and looks best.
My money is on the Ramp sight as it seems logical to make it look like a front sight... but who knows. They may have went for easy consistent and had a blunt suare cut like the MerrSonn... we may never know unless a pre -damaged Blaster image shows up!
