MonsieurTox
Master Member
Re: Y pattern
.................
.................
Last edited:
............
- Thread starter MonsieurTox
- Start date
- Status
Re: Y pattern
Incredible! The amount of clean, competent work you crank out is amazing!
Incredible! The amount of clean, competent work you crank out is amazing!
-... . .- --..
Sr Member
Re: Y pattern
So smooth!
So smooth!
Re: Y pattern
Julien, has your casting setup moved beyond pressure casting nowadays? I assume you still keep it simple, but the complexity of the castings you make seem complex.
Julien, has your casting setup moved beyond pressure casting nowadays? I assume you still keep it simple, but the complexity of the castings you make seem complex.
MonsieurTox
Master Member
Re: Y pattern
Thanks guys !
Scott, I never used a pressure pot for casting, only vacuum chamber and that's at work or at my friend's shop.
I dont own one of this setup myself so I never use it for my own project, I don't feel the need to replicate ILM castings (haha), even if they used those setups at least on ROTJ and probably on ESB (but it does not show if they did on ESB, on ROTJ the casting quality has greatly improved).
For the engine plant-on, I did not make the mold like I would have liked (2 parts RTV molds with vents).
The master was very fragile (the thickness of the spots were the parts are glued together is 0.3mm) so I felt more comfortable to glue the whole master on a blank Saturn V can.
I only made one RTV mold to capture te details but no back because I used another blank Saturn V can for the molding process. Of course I used demolding agent so the castings do not bond to the plastic (castings are very delicate and fragile).
This way is not the best way to make casting because I had no vents, resin goes into an enclosed cavity so you can easily have airbubbles (and big ones !) trapped into the mold (see DaveG's thread when he tried to mold the canopy and the scoop without vents, he had that problem
).
It's a bit tricky with to not get airbubbles, the process needs a lot of care and some practice. Fortunatly enough I already made some molds like that in the past so I had no problem to get good result. I pulled 16 castings (more than needed) and I only had one casting with an airbubble in it. TBH it worked better than expected, I was expecting a lot more rejects !
The body will be a nightmare to cast will all those details on the side but they did it so I can do it !
Haha Don,
Not sure you'd like it, I sanded the sides a lot (way too much, the walls are way to thin in some places now) to try to correct the shape. Unfortunatly I was not able to sand it more or I would have go through it. The sides were too much twisted on the V2, they are on the original, but not that much ! That's probably the most tricky place to nail on the cockpit.
Thanks guys !
Scott, I never used a pressure pot for casting, only vacuum chamber and that's at work or at my friend's shop.
I dont own one of this setup myself so I never use it for my own project, I don't feel the need to replicate ILM castings (haha), even if they used those setups at least on ROTJ and probably on ESB (but it does not show if they did on ESB, on ROTJ the casting quality has greatly improved).
For the engine plant-on, I did not make the mold like I would have liked (2 parts RTV molds with vents).
The master was very fragile (the thickness of the spots were the parts are glued together is 0.3mm) so I felt more comfortable to glue the whole master on a blank Saturn V can.
I only made one RTV mold to capture te details but no back because I used another blank Saturn V can for the molding process. Of course I used demolding agent so the castings do not bond to the plastic (castings are very delicate and fragile).
This way is not the best way to make casting because I had no vents, resin goes into an enclosed cavity so you can easily have airbubbles (and big ones !) trapped into the mold (see DaveG's thread when he tried to mold the canopy and the scoop without vents, he had that problem
). It's a bit tricky with to not get airbubbles, the process needs a lot of care and some practice. Fortunatly enough I already made some molds like that in the past so I had no problem to get good result. I pulled 16 castings (more than needed) and I only had one casting with an airbubble in it. TBH it worked better than expected, I was expecting a lot more rejects !
The body will be a nightmare to cast will all those details on the side but they did it so I can do it !
Ouh you need to clear some space for your model,I don't mind to take care of your V2
Don
Haha Don,
Not sure you'd like it, I sanded the sides a lot (way too much, the walls are way to thin in some places now) to try to correct the shape. Unfortunatly I was not able to sand it more or I would have go through it. The sides were too much twisted on the V2, they are on the original, but not that much ! That's probably the most tricky place to nail on the cockpit.
Last edited:
Re: Y pattern
Thanks for the insight regarding your casting methods. I like that idea of using the Saturn V can as the back of the mold!
Thanks for the insight regarding your casting methods. I like that idea of using the Saturn V can as the back of the mold!
MonsieurTox
Master Member
Re: Y pattern
Only used because I was in a rush and I had to glue the master on something strong, I would not recommand it but regular RTV with vent and pour holes !
Only used because I was in a rush and I had to glue the master on something strong, I would not recommand it but regular RTV with vent and pour holes !
steve_jones
Active Member
Re: Y pattern
Great works as always!
I know the answer to this will probably be no, but are you planning to sell casts of the model when your done
Im sure there would be a few interested parties around here !
Great works as always!
I know the answer to this will probably be no, but are you planning to sell casts of the model when your done
Im sure there would be a few interested parties around here !
MonsieurTox
Master Member
Re: Y pattern
Thank you Steve, I'm not planning to sell Y parts, but we never know, If the molds cost me too much, maybe I'll sell one or two.
You have DaveG Y, if you're interested in building your own, or the eFX Y-Wing (that Ive been told should be released in the next decade just kidding), it is awesome but you'll be stuck with a finished model of Gold Leader, you won't be able to build any other out of it without a lot of work. Better start from DaveG Y.
Great works as always!
I know the answer to this will probably be no, but are you planning to sell casts of the model when your done
Im sure there would be a few interested parties around here !
Thank you Steve, I'm not planning to sell Y parts, but we never know, If the molds cost me too much, maybe I'll sell one or two.
You have DaveG Y, if you're interested in building your own, or the eFX Y-Wing (that Ive been told should be released in the next decade
just kidding), it is awesome but you'll be stuck with a finished model of Gold Leader, you won't be able to build any other out of it without a lot of work. Better start from DaveG Y.steve_jones
Active Member
Re: Y pattern
Thanks Julien I am looking at daves build as well, but I don't think I would ever be able to afford all the required kit parts needed to make one so was looking at alternatives, will still watch this with interest
Thanks Julien I am looking at daves build as well, but I don't think I would ever be able to afford all the required kit parts needed to make one so was looking at alternatives, will still watch this with interest
MonsieurTox
Master Member
Re: Y pattern
.................
.................
Last edited:
MonsieurTox
Master Member
MonsieurTox
Master Member
Re: Y pattern
Thanks Ron !
Thanks Ron !
