Started a test to see if the EVA will work for making a few guns. Doing these as speed builds so probably not going to be exact or perfect. I should have these both finished in 2 or 3 days tops.

First I made a quick drawing of the M8 Assault Rifle and cut it out of the foam. I cut channels inside and inserted a skeleton to keep it rigid. Got the cores for both guns cut, assembled and rough sanded the edges. Also got the next layers for them rough cut. 2 layers thick for the core of the gun. It will be 6 layers thick in total using the 1/2 inch thickness foam. This means a lot of seams on the edges but I plan to skin just about everything with 1/8 thick foam sheeting. At this point I'm just building it up to then sand down into the proper shape.



[EvilFX]

I when you curved you chest piece, did you already have it assembled (the chest/ribs/abs), or did you wait til after?

Also I'm thinking about applying this to some other projects but was wondering how many of those mats has it taken to make the male suit. I'm 6'10, so I'm trying to gauge how many I might need.

I shape them first then glue them,.. otherwise heating the foam to shape would soften the glue.

For each suit I think I used about 4 packs. (about 16 sheets)

Was wondering if these were the EVA sheets you purchased? They sound exactly as what you have described here...

Google Image Result for http://cdn.dealsdirect.net/m/products/358/22358/1/product1_22358_600x600.jpg

and did you use a black and gray color or just gray and the backing is black?

Yes they look to be the same as what I am using, I buy mine locally from Harbor Freight. Mostly Grey colored but I did use some black for some of the parts backing.

how did you do the compound curves? What was used to cut the material cleanly? If you use scissors on foam, you don't get a square cut, its more "wedge" cut.

Check the earlier posts on my N7 Armor Blog where I show the tools and forms I made for shaping some of the compound curves. (as in boobs)
