JFcustom's FOAM files

Discussion in 'Replica Costumes' started by JFcustom, May 24, 2012.

  1. Kurtis876

    Kurtis876 Active Member RPF PREMIUM MEMBER

    Trophy Points:
    431
    Re: FOAM speed-building files'n'tricks : added Dancin_Fool's Iron Man MkII/III

    awesome ok great thank you bud! Couldn't risk wasting paper today unfortunately. I appreciate your help! :thumbsup

  2. Dancin_Fool

    Dancin_Fool Well-Known Member

    Trophy Points:
    747
    Re: FOAM speed-building files'n'tricks : added Dancin_Fool's Iron Man MkII/III

    When I'm doing it what I do is turn on alignment marks in pep designer. This puts crosshairs in the 4 corners. Then after printing you can just connect the crosshairs with a ruler and pen and you'll know perfectly where the piece ends, then you just have to tape them together.

    CyberPaddy66 likes this.
  3. Kurtis876

    Kurtis876 Active Member RPF PREMIUM MEMBER

    Trophy Points:
    431
    Re: FOAM speed-building files'n'tricks : added Dancin_Fool's Iron Man MkII/III

    ok, I did try that but it ended up printing nothing when I tried to print. I unplugged and restarted pc and printer, seems to be back on track. Thanks DF! I know you've heard it 5,000 times, but your work is top shelf! :thumbsup

  4. Kurtis876

    Kurtis876 Active Member RPF PREMIUM MEMBER

    Trophy Points:
    431
    Re: FOAM speed-building files'n'tricks : added Dancin_Fool's Iron Man MkII/III

    another question, this is for anyone working with the mark iii JF files, do you know if they are all scaled to each other? it looks as though most are scaled to 1.6555, except the neck (as i've seen so far). That is, Do you think all the files can be scaled down by the same percentage?

    So far I've built the arm in paper, and the shoulder, and they seem pretty large on me, i'm scaling them down 20%. I want a pretty fitted suit as I'm a decent size lad already. I'm 5'10", 180 lb., 33" waist, and am trying to get a smaller look in general than I've seen many builders get. Anyway, the long-winded point is I feel like I'm already a decent-sized dude, and don't need the suit to look oversized as some folks get.

    Thanks everyone! :)

    Last edited: Jul 26, 2012
  5. spideyman12004

    spideyman12004 Active Member

    Trophy Points:
    341
    Re: FOAM speed-building files'n'tricks : added Dancin_Fool's Iron Man MkII/III

    Wanted to thank JF for the files. I went out and bought some 1/4" camping foam ($10 for a 70" x 39" roll) but I find it to soft. Has only one else use this type of foam before or should I try something else?

  6. Deelite

    Deelite Active Member

    Trophy Points:
    342
    Re: FOAM speed-building files'n'tricks : added Dancin_Fool's Iron Man MkII/III

    Well, once you start doing the painting process, it'll get "stiffer". Don't worry about the softness now.

  7. spideyman12004

    spideyman12004 Active Member

    Trophy Points:
    341
    Re: FOAM speed-building files'n'tricks : added Dancin_Fool's Iron Man MkII/III

    I just find with this foam I'm unable to get any angle cuts even with a new blade. I get one angle cut for the mountain and when I go to do the other the foam just bunches up making one horrible cut line

  8. Kurtis876

    Kurtis876 Active Member RPF PREMIUM MEMBER

    Trophy Points:
    431
    Re: FOAM speed-building files'n'tricks : added Dancin_Fool's Iron Man MkII/III

    I found camping foam too flexible... though I know a lot of people use it. I get mine from "wandy_foam" on ebay. Just search for 6mm foam sheets and it should come up. It's eva foam that is just the right amount of thickness+flexible. It's probably about twice as expensive...

    Another option is Joann.com, they have 6mm "Darice" eva foam sheets, about $1 per 12x9 sheet... however they have it on sale right now, you can get a 10 pack for $6.49. Just search for 6mm foam. Joann always has some kind of coupon you can use too. Hope this helps!

  9. Kurtis876

    Kurtis876 Active Member RPF PREMIUM MEMBER

    Trophy Points:
    431
    Re: FOAM speed-building files'n'tricks : added Dancin_Fool's Iron Man MkII/III

    I sometimes use this bevel foam cutter, it works decently with a good blade:

    Amazon.com: Foamwerks Straight/Bevel Cutter: Arts, Crafts & Sewing

    Otherwise you could try a hotknife, or a box cutter. Angles on a curve are definitely tough sometimes, anyone else have suggestions?

  10. spideyman12004

    spideyman12004 Active Member

    Trophy Points:
    341
    Re: FOAM speed-building files'n'tricks : added Dancin_Fool's Iron Man MkII/III

    Thanks for the suggestions. I've looked into "wandy foam" on ebay but it says they don't ship to Canada. I'll try out Joann.com. Thanks again

  11. Kurtis876

    Kurtis876 Active Member RPF PREMIUM MEMBER

    Trophy Points:
    431
    Re: FOAM speed-building files'n'tricks : added Dancin_Fool's Iron Man MkII/III

    dang sorry! man... there are so many Canadians on here... you guys must love costumes up there! :thumbsup

  12. spideyman12004

    spideyman12004 Active Member

    Trophy Points:
    341
    Re: FOAM speed-building files'n'tricks : added Dancin_Fool's Iron Man MkII/III

    Thought I'd give it another shot with this foam. Had enough to just do the right shin. Still need some work on size and angles. But other then that, didn't come out to bad for my first try

    http://s1062.photobucket.com/albums...deyman12004/?action=view&current=DSCF0890.jpg

    http://s1062.photobucket.com/albums...deyman12004/?action=view&current=DSCF0891.jpg

    http://s1062.photobucket.com/albums...deyman12004/?action=view&current=DSCF0893.jpg

  13. vargatom

    vargatom Member

    Trophy Points:
    191
    Re: FOAM speed-building files'n'tricks : added Dancin_Fool's Iron Man MkII/III

    Foam can be shaped well with a heat gun. Try to make less cuts in curved areas and bend the foam instead, it'll look better. Takes a little practice to find out how to modify the pep files and how to use the heat gun... also consider buying a pair of gloves at your hardware store!

  14. Kurtis876

    Kurtis876 Active Member RPF PREMIUM MEMBER

    Trophy Points:
    431
    Re: FOAM speed-building files'n'tricks : added Dancin_Fool's Iron Man MkII/III

    Man that looks great! Obviously the lighter colored foam helps you see edges as you cut. Great job!

  15. Kurtis876

    Kurtis876 Active Member RPF PREMIUM MEMBER

    Trophy Points:
    431
    Re: FOAM speed-building files'n'tricks : added Dancin_Fool's Iron Man MkII/III

    I gotta say I love these files JF and DF! this mk iii is definitely the most foam friendly I've used! I have the right leg done, though I keep forgetting to take pics. I want to do a little more thermoforming on the calf too. I wish I had seen these before I built stealth's torso... though his is awesome too, I really like the simplicity of these!

    It seems that the Mark III DF, JF, and stealth files are all interchangable at the same scale...that of course would make sense right, since they are all from the DF files? I'm going to add the JF spine to the stealth back today, seems like it should fit according to the cardstock cutout. Thank you so much JF, DF, and Stealth!

  16. mark0017

    mark0017 Well-Known Member

    Trophy Points:
    567
    Re: FOAM speed-building files'n'tricks : added Dancin_Fool's Iron Man MkII/III

    These tips and tricks are invaluable mate, many thanks for making foam building a hell of a lot easier......oh and i borrowed your idea for making the arc reactor, it works really well so thanks very much (y)thumbsup

  17. Kurtis876

    Kurtis876 Active Member RPF PREMIUM MEMBER

    Trophy Points:
    431
    Re: FOAM speed-building files'n'tricks : added Dancin_Fool's Iron Man MkII/III

    ok guys, Just thought I'd post a quick pic... My first full foam IM build is almost complete. I'll probably post a new thread with pics I've taken over the last 3 weeks... Clearly I had no idea how much foam it would take haha! I'll post more in the future. This was built using JF's custom files, and DF's arm files, mixed with Stealth's chest and back DF edits.

    What took the longest was the abs, I somehow got it in my head that I wanted to do them from scratch, which ended up taking forever. Fits pretty well though! Overall, I must say there was a BUNCH of customizing, but thanks so much for the great files guys!!

    My main and probably only problem is that the biceps fit pretty tight, but look too big! I might have to rebuild them using 4mm foam. (y)thumbsup:thumbsup

  18. JFcustom

    JFcustom Sr Member

    Trophy Points:
    1,085
    Re: FOAM speed-building files'n'tricks : added Dancin_Fool's Iron Man MkII/III

    Excellent job !
    What did you use to dig the dark lines on, for exemple, the brown leg ? it looks realy workmanlike.

  19. electraflier

    electraflier Well-Known Member

    Trophy Points:
    866
    Re: FOAM speed-building files'n'tricks : added Dancin_Fool's Iron Man MkII/III

    I have to agree with JF, those seam lines are so straight and clean they almost look machined....but it is foam right??
    Eager to hear how you accomplish those!
    Maybe the secret is a well stocked bar??? hmmm maybe onto something here spideyman.:lol
    M

    Last edited: Aug 22, 2012
  20. Kurtis876

    Kurtis876 Active Member RPF PREMIUM MEMBER

    Trophy Points:
    431
    Re: FOAM speed-building files'n'tricks : added Dancin_Fool's Iron Man MkII/III


    HAA! wow that's really a compliment man thanks to you both!

    Welllllll what it is is... A hotknife. I drew out the lines I wanted, using a ruler and a flexicurve, following movie stills and a 10" mk iii toy I have, as well as a great file i found on turbosquid. After I layed them all out, I "burnished" them about one mm deep into the foam, slowwwly but surely. It was high risk, but I felt I had the practice for it. Any tiny mess-ups I will go back and do fine battle damage in the paint stage. I've been going for a simple look that still looks detailed enough to be not cheap, slightly movie-esque, and hopefully will look good come paint time.

    As I progressed, I learned good speed, pressure, and angle of the knife, which helped get a lot of the edges continuous. Plus, sometimes the lines I needed follow the actual Foam seams, so that also to care of some imperfections. PLEASE practice on scrap if you're going to attempt the hotknife! I used a tiny (almost looks like a ballpoint pen) knife nib (DOES NOT look like the xacto blade), cranked the heat up to orange/red, and kept my hand steady. Boom. It's something I attempted many times, but I actually got a tip from Mr. Bibou which helped. Props to him!

    Yes, I used 2, 3, 4, and 6mm EVA foam, Darice and some from "wandy foam" on ebay, which was EXCELLENT (the light tan). There are definitely differences in ease of cutting amongst brands of foam companies.

    There are alot of cool little zippers, snaps, chicago screws, and velcros that I'll post more of later.

    The suit will be topped with either my Pannaus or Finhead lid (Tjack made), so I'm pumped!

    But I will say to anyone, start with good templates, nice cutouts, sharp blades, and take your time, you can get some really great edges! I'll post more pics in the future, thanks again everyone! (y)thumbsup:thumbsup

  21. Kurtis876

    Kurtis876 Active Member RPF PREMIUM MEMBER

    Trophy Points:
    431
    Re: FOAM speed-building files'n'tricks : added Dancin_Fool's Iron Man MkII/III

    Oh yes, and don't forget the well stocked bar (let me know if you find one) (y)thumbsup:thumbsup

  22. Addamisk1

    Addamisk1 New Member

    Trophy Points:
    16
    Re: FOAM speed-building files'n'tricks : added Dancin_Fool's Iron Man MkII/III

    jf you are a gentleman and a scholar

  23. SneakyDerezzer

    SneakyDerezzer Member

    Trophy Points:
    180
    Re: FOAM speed-building files'n'tricks : added Dancin_Fool's Iron Man MkII/III

    JF, I was planning to use your Mark 4 templates for my foam/resin build I am starting. I am 5 ft 8 inches tall. Would the default scale on your converted Mk. 4 fit me?

    Or do you think I should measure each piece to my body parts?

  24. JFcustom

    JFcustom Sr Member

    Trophy Points:
    1,085
    Re: FOAM speed-building files'n'tricks : added Dancin_Fool's Iron Man MkII/III

    About this legitimate scaling question, the suit you've chosen is by default scaled for a 1m83 guy (6'). If you're 1m73 (5'8") and don't want to look like a squirrel in a spacesuit, you just have to compute for all file the folowing [default_scale_ratio x (173/183)] to you obtain your own scaling value.

    Here the scale ratio is set to sommething like 25 ? Or whatever else, it's simply an unconcrete value that represents nothing you can mesure, but it's a value set for someone of 1m83. If you're smaller, this value must be smaller, by a proportionnal and linear factor. For a ratio of 25, your result will be near 23,64. Imput this value insted of the 25, click OK, then tweak the alignment of sheats borders by moving your 2D shapes if needed (paper templates will be smaller, but paper sheats's size remains the same, so you'll have the feeling that your templates have moved to the top left corner of the 2D view), and at last print your templates.

    This is the basical way to operate. But if you know you have realy short legs and long arms, for example, you may want to take measurements on your body and specify a well matching ratio for each of your suit parts... I don't like this approach because IMO it breaks the harmony of proportions.
    _______

    Oh, and I'm 178, and did not rescale my mk4 suit. You may notice from pictures that it'a bit too large. I don't like a suit to constrict me as tight as a coat of paint.

    Last edited: Aug 29, 2012
    Laura McGregor likes this.
  25. JFcustom

    JFcustom Sr Member

    Trophy Points:
    1,085
    Re: FOAM speed-building files'n'tricks : added "Howto sharpen a blade".


    How to sharpen a blade.



    I read in almost every thread about issues with foam clean cutting that several dozens of new blades can be needed to build a full suit. Of course we all agree on the requirement of a highly sharp blade, and the less we can say is that a supersharp blade does not stay supersharp for a long time at all.

    It mustn't be a reason to replace it systematically. Only the very edge of the blade is blunt, don't waist it for such a short. There are many ways to sharpen it back. You're allowed to disbelieve : I use the same blade since april. I'm a tightwad... :D

    If foam by itself is able to blunt a blade, this same foam may also sharpen it. The main trick is NOT to take an aggressive nor fierce material. No whetstone, no grindstone, no polishing Dremel tip, not event the thinest sanding paper... Something just like Death, in "Reaper man" from Terry Pratchett, is sharpening his scytheblade using wind and moonlight until it can even cut a conversation.

    Here we must choose a couple of tools, that will widely depend of what you can find around you :
    - a long and soft one, like the wooden stick of your sweeper.
    - a hard and sleek one, for exemple the handle of a steel ladle,
    An object with a circular section works better. Too flat and the blade won't press enough, too thin and it will press too much.

    HOWTO :

    The way you would lay down some marmelade on a toast, scrub with some wide movements each side of the slanted blade on the surface of your wooden stick. On all the length of the blade, always in the same direction. Do not press at all ! the weight of the cutter is enough. Do it lightly and tactfully. Wood is slightly abrasive, it will polish the edge of the blade. Then, do the same on the steel handle. Metal is hard and bald, it will flatten the imperfections. Do it ten times on each side with each tool, and check the sharpness on a small wasted piece of foam. Do it frequently, don't wait your blade to be worn out before doing it again.

    You can also use a strip of cardboard, the side of a shoebox, an empty roll of kitchen paper,even a tissue flap... a copper pipe, the side of your desktop computer, a metal doorknob or chair leg...

  26. IMIM2

    IMIM2 Sr Member

    Trophy Points:
    1,306
    Re: FOAM speed-building files'n'tricks : added "Howto sharpen a blade".

    JF!!!!!!
    That is a marvelous tip.
    X-acto blades cost a fortune to me. This is a nice trick.
    Perhaps I'd do with bended popsicle stick. In the mean time, I'll look again for my recently broken sweeper stick :lol.
    I have been told that we must hold the knife at 20 degree angle?

  27. Spydwar

    Spydwar Active Member

    Trophy Points:
    331
    Re: FOAM speed-building files'n'tricks : added "Howto sharpen a blade".

    Thank you for another of many wonderful tips. I too am a bit of a tight wad and this was one of the biggest draw backs of this hobby. Will be trying this tonight thanks again.

    -----------------------------------------------------
    Iron man Mk4 first attempt http://www.therpf.com/f24/ironman-mk-4-first-attempt-foam-build-158310/

  28. omel

    omel Well-Known Member

    Trophy Points:
    935
    Re: FOAM speed-building files'n'tricks : added "Howto sharpen a blade".

    Oldtimer barbers sharpen their razors on leather belts, i believe this can be utilized for re-sharpening cutter blades as well.

  29. JFcustom

    JFcustom Sr Member

    Trophy Points:
    1,085
    Re: FOAM speed-building files'n'tricks : added "Howto sharpen a blade".

    Yes, we can see them doing so in some western movies.
    About the inclination, something between 20 and 30 degrees angle will go. Below : the tool doesn't touche the apex of the blade at all, and above : it crunches it.
    _______

    Oh, and by 10 times on each side, I ment left side and right side alternatively, not 10 tilmes letf and 10 times right. Just like the barbers. It's important to work on both sides in parallel.

  30. chebioc

    chebioc New Member

    Trophy Points:
    2
    Re: FOAM speed-building files'n'tricks : added "Howto sharpen a blade".

    :thumbsup Thanks for the Tip! Really appreciate it! :thumbsup

  31. donchewliano

    donchewliano New Member

    Trophy Points:
    16
    Re: FOAM speed-building files'n'tricks : added "Howto sharpen a blade".

    wow. Awesome thread. Thanks. This will be useful for a newb like me.

  32. TVsRobLowe

    TVsRobLowe Active Member

    Trophy Points:
    342
    Re: FOAM speed-building files'n'tricks : added "Howto sharpen a blade".

    Great writeup.

    Does anyone know of a US supplier of the plastic clip rivets that JF used? I've been searching this morning and the only thing I can find are regular rivets or automotive push clips.

  33. Kurtis876

    Kurtis876 Active Member RPF PREMIUM MEMBER

    Trophy Points:
    431
    Re: FOAM speed-building files'n'tricks : added "Howto sharpen a blade".

    Ill look into it... I just had to say how genius your user name is

  34. kyxz2

    kyxz2 Active Member

    Trophy Points:
    342
    Re: FOAM speed-building files'n'tricks : added "Howto sharpen a blade".



    Hey, this is a good tip, you can also use and old jeans. That's what I use for sharpening my razor.

  35. Catavarie

    Catavarie Member

    Trophy Points:
    191
    Re: FOAM speed-building files'n'tricks : added "Howto sharpen a blade".

    JF - Thanks for your files and all the great information you have provided here.

    Another tip for sharpening your blade, to ensure you're doing it right and completely. Take a Sharpie marker and mark both sides of your cutting edge. As you sharpen the blade properly the marker will be uniformly ground away as well. This is a great way to check that you're getting the proper angle on the blade while sharpening it.

  36. JFcustom

    JFcustom Sr Member

    Trophy Points:
    1,085
    Re: FOAM speed-building files'n'tricks : added "Howto sharpen a blade".

    Thank you Catavarie, crafty tip. I quote this in the first post.

  37. PropGeek

    PropGeek New Member

    Trophy Points:
    16
    Re: FOAM speed-building files'n'tricks : added "Howto sharpen a blade".

    Very interesting stuff! Thanks to all who contribute to this thread!

  38. Sonjou

    Sonjou Well-Known Member RPF PREMIUM MEMBER

    Trophy Points:
    666
    Re: FOAM speed-building files'n'tricks : added "Howto sharpen a blade".

    Thanks for all the tips and tutorials.
    And thanks for putting it all in the first post!

    Mark

  39. JFcustom

    JFcustom Sr Member

    Trophy Points:
    1,085
    Re: FOAM speed-building files'n'tricks : added IM mk6.

    All in the first post, I find it practical.

    mizuno hadouken | theRPF (the guy with the stunning blue-Iron-Man) made me notice I had not released any foam file for the mkVI chest and brace.
    Well, now it's done.

  40. mizuno hadouken

    mizuno hadouken Well-Known Member

    Trophy Points:
    557
    Re: FOAM speed-building files'n'tricks : added IM mk6.

    Thank you for the update and thanks for the compliment!

  41. Black Card

    Black Card New Member

    Trophy Points:
    2
    Re: FOAM speed-building files'n'tricks : added IM mk6.

    Hey JF, is there a pep version of the Ultimate Iron Man?

  42. JFcustom

    JFcustom Sr Member

    Trophy Points:
    1,085
    Re: FOAM speed-building files'n'tricks : added IM mk6.

    This Ultimate is released here for foam, on the first post of this thread, and there for paper, in the first post of EyeOfSauron's pep files thread.

  43. brothergrimm

    brothergrimm New Member

    Trophy Points:
    16
    Re: FOAM speed-building files'n'tricks : added IM mk6.

    Heya guys. I'm almost done with my Batman suit. Looking towards the next project. Has anyone converted EOS's classic Iron Man to foam yet? I've been checking around. If the foam files are posted can someone direct me to the link. Thanks. And as always JF your threads and work rock. Thanks.

  44. JFcustom

    JFcustom Sr Member

    Trophy Points:
    1,085
    Re: FOAM speed-building files'n'tricks : added IM mk6.

    Might be a good alternative to the clips I use (and maybe available in the US ?)

  45. GRINCH

    GRINCH Well-Known Member RPF PREMIUM MEMBER

    Trophy Points:
    666
    Re: FOAM speed-building files'n'tricks : added IM mk6.

    I'm getting "cannot load file of specified type" in pepakura. What am I doing wrong?

  46. JFcustom

    JFcustom Sr Member

    Trophy Points:
    1,085
    Re: FOAM speed-building files'n'tricks : added IM mk6.

    You'll find your *.pdo files inside the *.rar file.
    A rar file is like a zip file. You need to download and install WinRAR to open rar files. It also opens zip files and many other archive formats.

  47. 7sinzz

    7sinzz Well-Known Member

    Trophy Points:
    566
    Hey jf, did you manage to finish the iron woman files buddy? Sorry to keep on about it.

  48. JFcustom

    JFcustom Sr Member

    Trophy Points:
    1,085
    Re: FOAM speed-building files'n'tricks : added IM mk6.

    Hi 7sinzz,
    well to tell you the truth, the fact that this modeling seems to remain definitively uncomplete has undermined my motivation. And as I'm short in time these days I had to relay the unfolding work through this thread untill I can find time enough to resume it back. You can see many want to start right now, I'm sure that a modeler from theRPF will soon consider feminizing a full suit.

  49. 7sinzz

    7sinzz Well-Known Member

    Trophy Points:
    566
    Hey no worries jf. Your work here is fantastic buddy, you do more than enough for this community. I've participated in that thread now.

  50. avallarino

    avallarino New Member

    Trophy Points:
    16
    Re: FOAM speed-building files'n'tricks : added IM mk6.

    Thanks for the tips. Very helpful!


Share This Page
