HERO LEVEL Fallout 3 Plasma Rifle FINISHED- Plus Pro Photo Shoot- First Post

Discussion in 'Replica Props' started by unorthodoxdesig, Jan 12, 2012.

  1. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    ***NEW PICS HAVE BEEN PUT IN FIRST POST FOR EASE OF VIEWING***


    Hey all, this thread represents almost 2 years of work to create this gun... Not a lot of free time I'm afraid.. Next I want to build ENCLAVE POWER ARMOR to go with it.. That'll take even longer probably :D

    This gun was inspired by everything VOLPIN has done, as well as CitizenSnips (flickr) who pulled off the first hero-level plasma gun build. I tried to make mine unique enough where it wasnt a direct copy.

    Thanks for looking!


    Here's the links

    The Plasma Rifle by Mike Cameron at Coroflot

    UNORTHODOX DESIGN | OFFICIAL SITE

    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]

    Last edited: Mar 23, 2015
  2. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    [​IMG]

  3. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    haha here we go...
    [​IMG]

  4. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    [​IMG]
    [​IMG]

  5. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
  6. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    [​IMG]
    [​IMG]

  7. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    [​IMG]
    [​IMG]

  8. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
  9. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    [​IMG]
    [​IMG]

  10. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    [​IMG]
    [​IMG]

  11. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    [​IMG]
    [​IMG]

  12. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    [​IMG]
    [​IMG]

  13. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    [​IMG]
    [​IMG]

  14. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    [​IMG]
    [​IMG]

  15. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    [​IMG]
    [​IMG]

  16. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    [​IMG]
    [​IMG]

  17. Darth Brass

    Darth Brass Sr Member

    Trophy Points:
    1,241
    Re: Fallout 3 Plasma Rifle

    Holy crap, dude! That's looking amazing!

  18. Skaar

    Skaar Active Member RPF PREMIUM MEMBER

    Trophy Points:
    441
    Re: Fallout 3 Plasma Rifle

    Amazing job man

    you should frame the drawing of it that would look awesome too :)

  19. Knowone251

    Knowone251 Well-Known Member RPF PREMIUM MEMBER

    Trophy Points:
    666
    Re: Fallout 3 Plasma Rifle

    holy mother! Talk about a serious build. That looks amazing, and your attention to detail is superb. How many different materials are being used for this one prop?!

  20. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    Well... the base is MDF, acrylic tubes, styrene sheet and extrusions, metal handles for the vanes at the front, steel strips for the front of the rifle stock (for rigidity when attaching to main body), ABS pipe for main yellow body and portholes, abs strips for rifle stock, black walnut wood for all grips, LED arrays and bulbs for lighting, wire, various bits of old hardware, various types of tubing

    hmmm I think that's it hehe.. It's taken 4 months so far so I've just been cobbling pieces together as I find solutions to making the various components. Thanks for the support!

  21. Macjedi

    Macjedi New Member

    Trophy Points:
    16
    Re: Fallout 3 Plasma Rifle

    WOH! I always find props with lights like this awesome....what a beautiful prop.

  22. neojun77

    neojun77 New Member

    Trophy Points:
    2
    Re: Fallout 3 Plasma Rifle

    awesome!!! Great work man.

  23. Confusius

    Confusius New Member

    Trophy Points:
    16
    Re: Fallout 3 Plasma Rifle

    Niiice! I especially like the wooden gun handles. Like fresh from a Winchester!

  24. idahorandom

    idahorandom Member

    Trophy Points:
    192
    Re: Fallout 3 Plasma Rifle

    Holy %$#@%&!

    That is amazing, I think I am in Love!:love

    Truely a work of art....

  25. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    Anyone have any other forms of weathering they've found to be realistic? I kind of want ore texture on the rusted areas.. also the green frame of the gun needs some work.. I don't know yet if I want to represent oily corroded plastic or painted metal.. suggestions?

  26. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
  27. Drewid

    Drewid Well-Known Member

    Trophy Points:
    856
    Re: Fallout 3 Plasma Rifle

    That is amazing!

    For weathering, I've used the Sophisticated Finishes with reasonable success. You can have copper patinas, a natural rust effect (with real rust), and a few others. I used the pewter kit on my PipBoy3K and the paint job turned out nicely.

    Sophisticated Finishes

    Rust-O-Leum has a few options too:

    RustOleum.com

  28. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    yeah I've seen some of the rustoleum stuff.. also looking into thinned oil paints as a final pass.. I'll check into the sophisticated finishes though thanks!

  29. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    NEEDED: SOMEONE WITH A BETTER UNDERSTANDING OF ELECTRONICS THAN ME

    okay so I have a 9V battery, a (220, 1/4 ohm)resistor, and 3x 3V LED's wired in sequence. Worked fine. Then I added a toggle switch (the silver flicky switches like on airplanes) and suddely only the middle LED lights up..

    All the LED's work when tested individually.. so what happened to my circut!?!?!

    GRRRR.. on the plus the delay that caused made me consider redoing my 6 portholes which had a few errors in their constructon..

  30. Drewid

    Drewid Well-Known Member

    Trophy Points:
    856
    Re: Fallout 3 Plasma Rifle

    What happens when you wire in two LEDs instead of three? It's very odd that it's the middle LED that lights up. If you move them around, is it the same one that lights?

    Here's one fact: you barely have enough potential (voltage) to drive the circuit. You have a 9V battery (which is probably closer to 8.7) and three 3V LEDs (which can be anywhere between 2.7V and 3.3V). V = Vs - Vf = 9 - 3 - 3 - 3 = 0.

    Now here's a guess: the switch may have a drop of 0.1V or less (cause it's not a perfect conductor) and that's enough to tip the scales. The power requirements of that middle LED might be just that much less than it's two brothers enough to light up.

    You'd be better off wiring the LEDs in parallel after the switch. The downside to that is you use more current and drain the battery faster.

  31. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    okay yeah that's what I was thinking wire them in parallel.. the only thing that still doesn't make sense (at least to me) is I tried it again with a 12 V battery pack (9v plus 2xAA) and only one went on still!! My problem i think is I added the lights to the assembly prematurely.. next time I'll do the entire wiring, test, and then worry about installation.

    Thanks though I'll try that.
    would I need to put a resistor on each LED line or just one after? the battery?

    sorry I want to aspire to greater electronics knowledge but just haven't had a chance yet heh..

  32. Drewid

    Drewid Well-Known Member

    Trophy Points:
    856
    Re: Fallout 3 Plasma Rifle

    How did you have the AA batteries wired in? If they were in series that should have produced 12V. If you wired the AAs in parallel with the 9V you'll still have only 9V.

    You should have a resistor per LED. The reason is that electrons are picky and will choose the path of least resistance. But a resistor is a voltage drop and will guarantee that current will flow through it inversely proportional to the size of the resistor (the math can get a little funky). If you have to drive lots of LEDs, a combination of parallel and series works nicely. Say you have to drive six 3V LEDs on a 9V battery. You can split them up into three sets of two. This way the effective voltage is 3V across the resistors and each current stream powers two LEDs.

    If you haven't seen this yet, I recommend checking it out: Light Emitting Diodes (LEDs)

  33. theobeau

    theobeau Member

    Trophy Points:
    191
    Re: Fallout 3 Plasma Rifle

    Congratulations on the rifle....simply amazing.

    Made me want to boot up FO all over again!

  34. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    I LEARNED A LESSON...

    When you feel a component of your prop is visually.. weak.. do something about it. sometimes an underestimated component can be a slight detraction.. or can be one of the visual highlights...

    I was never happy with the old portholes.. not beefy enough, so I reinforced them with epoxy putty.. still no.

    So since my wiring if going to have to be redone, here is the also redone portholes.. Now a somewhat crappy looking piece of the prop has become the visual highlight it should be.

    Enjoy!

  35. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    [​IMG]

    old portholes

  36. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    [​IMG]
    [​IMG]
    [​IMG]

  37. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    [​IMG]

    the depth is created through the use of 1/4 inch thick acrylic.. makes it look like reinforced glass instead of floppy thin stuff

  38. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    [​IMG]
    OOOHHH SHINY!!! like I said I think this is quite an improvement over the old version.
    (dry assembly, the nuts are a little out of place.. )
    This is why you must develop each piece of something to it's full potential. Working with plastics for nice finishes for chrome is so much easier than dicking around with MDF.. also much more expensive :D

  39. Surge

    Surge New Member

    Trophy Points:
    3
    Re: Fallout 3 Plasma Rifle

    aww I can't see you're latest pics dude (links wrong?) :(... the build looks amazing so far!

  40. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    [​IMG]
    [​IMG]
    [​IMG]

  41. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    [​IMG]
    [​IMG]
    [​IMG]

    have to remember to be signed out before i copy the pic link..

  42. zanthious

    zanthious New Member

    Trophy Points:
    2
    Re: Fallout 3 Plasma Rifle

    man, That looks amazing. I was coming in here for ideas and was blown away by how freaking professional that thing looks.

  43. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    [​IMG]
    coming together...

  44. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    [​IMG]
    argh I did it again! Let's try this...

  45. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    [​IMG]
    [​IMG]

  46. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
  47. Drewid

    Drewid Well-Known Member

    Trophy Points:
    856
    Re: Fallout 3 Plasma Rifle

    Wow! It just gets better and better. :thumbsup

  48. unorthodoxdesig

    unorthodoxdesig Active Member

    Trophy Points:
    341
    Re: Fallout 3 Plasma Rifle

    [​IMG]

  49. Lunarblue

    Lunarblue New Member

    Trophy Points:
    2
    Re: Fallout 3 Plasma Rifle

    very nice!
    love it!

  50. Cut Snake

    Cut Snake Active Member

    Trophy Points:
    332
    Re: Fallout 3 Plasma Rifle

    That's extreme. Love it, great job mate.
