Arc Reactor dimensions Help!

Don't want to see this ad? Sign up for anRPF Premium Membershiptoday. Support the community. Stop the ads.


fez79

New Member
Hi everyone, i'm searching for right, original dimension of the Arc Reactor, like the one that Pepper gives to Tony in the movie. I want to make a replica.


Which is the diameter of the bright ring? And the diameter of the outer metal ring that says "Proof that Tony Stark has a heart".

Thanks, regards
Federico


Don't want to see this ad? Sign up for anRPF Premium Membershiptoday. Support the community. Stop the ads.

nicom1234

Well-Known Member
RPF PREMIUM MEMBER
I cut one out of 'Dibond' Aluminium/plastic composite and applied vinyl letters. I made this PDF, it should be to 1:1 scale when printed. View attachment Proof Ring.pdf
There is a lathed aluminium piece that the light ring and kind of the whole thing sits into.


IAmTheClayman

Active Member
RPF PREMIUM MEMBER
When I built mine I made the center ring 3" in diameter. It's a number I got from several other build threads, and between the screenshots from the film and my own finished project it's definitely the right number. Good luck!


JamesBryan

Active Member
i hope this doesnt count as necro posting but just wanted to say thank you for this. the PDF was a big help and gave me the one measurement i needed to get my own build back on track.
