1966 Batman BatRadio/Transmitter scratchbuild

Discussion in 'DC Costumes and Props' started by PropReplicator2, Aug 13, 2018.

  1. PropReplicator2

    PropReplicator2 Sr Member RPF PREMIUM MEMBER

    Trophy Points:
    1,731
    So after years of waiting to build a batradio from the '66 Batman film, I have finally embarked on my journey to do so.

    The original prop was carved from a single block of wood and was very messily done (not uncommon for a B-prop), but mine will be constructed with several layers of styrene sheets and meticulously cut to create a cleaner-looking inside for a more as aesthetically pleasing product.

    First some images of the original:
    [​IMG]

    And some of where I an at currently, creating the back section with the cutout and cutting the front plate out:
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]

  2. PropReplicator2

    PropReplicator2 Sr Member RPF PREMIUM MEMBER

    Trophy Points:
    1,731
    Spent the last two hours cutting, sanding, and shaping the faceplate of the transmitter.. next to fill in with Bondo and shape with epoxy putty!
    [​IMG]
    [​IMG]
    [​IMG]

    vader45 likes this.
  3. PropReplicator2

    PropReplicator2 Sr Member RPF PREMIUM MEMBER

    Trophy Points:
    1,731
    After some filling, sanding, and priming here is the front view of the batradio:
    [​IMG]

    Last edited: Aug 14, 2018
    vader45 likes this.
  4. PropReplicator2

    PropReplicator2 Sr Member RPF PREMIUM MEMBER

    Trophy Points:
    1,731
    And a shot of the back side of the original compared to mine:
    [​IMG]
    [​IMG]

    vader45 likes this.
  5. 13doctorwho

    13doctorwho Sr Member RPF PREMIUM MEMBER

    Trophy Points:
    1,626
    Awesome project! I've been meaning to make this forever. I was think of going the 3D printing route (I've gotten lazy about scratch building). It's great to see something other than a grapple gun or batarang!

    PropReplicator2 likes this.
  6. PropReplicator2

    PropReplicator2 Sr Member RPF PREMIUM MEMBER

    Trophy Points:
    1,731
    Haha! Too many batarangs and grapple guns, so I had to switch it up a bit. I'm a member over on the '66 forums as well but don't see as many Adam west Batman builds here...
    The belt will be next if all goes as planned ;)

    And just FYI.. I just posted and interest thread up for resin kits in the run section to anyone who is interested :) https://www.therpf.com/showthread.php?t=293617

  7. Meule

    Meule Active Member

    Trophy Points:
    341
    Looking good so far

    Yeah, I would love to see more Batman 66 props here

    Grayvette03 and PropReplicator2 like this.
  8. PropReplicator2

    PropReplicator2 Sr Member RPF PREMIUM MEMBER

    Trophy Points:
    1,731
    Hopefully I'll be able to change that.. I'm building the belt and pouches next and will be documenting that as well. Then it's on to remaking my batshield and batzooka!

  9. Meule

    Meule Active Member

    Trophy Points:
    341
    I started working on a Batzooka, but then decided to make the Thermodynamic Ice Ray Beam, which uses the same Mattel Sonic Blaster (and is easier to make :p )
    I really should get back to the Batzooka, but I can't seem to find a consensus on whether the Batzooka was black or navy blue.

    PropReplicator2 likes this.
  10. PropReplicator2

    PropReplicator2 Sr Member RPF PREMIUM MEMBER

    Trophy Points:
    1,731
    I am about 95% sure it is black, just because most of the photos I've seen show it as black and not blue, but then again lighting and photo quality is everything ;)

  11. PropReplicator2

    PropReplicator2 Sr Member RPF PREMIUM MEMBER

    Trophy Points:
    1,731
    Holy lack of updates Batman! Getting some better resins to cast in tomorrow and should be able to get all of these cast quite quickly. As far as electronics go, I've finally found a place that sells push buttons small enough to fit in the radio front under the custom-cast button. Stay tuned!

    Mike J. likes this.
  12. PropReplicator2

    PropReplicator2 Sr Member RPF PREMIUM MEMBER

    Trophy Points:
    1,731
    Alrighty, so 5 test casts later and I've finally got the process down good enough to offer these with pride ;)

    Right out of the mold:

  13. alexa0ne

    alexa0ne Jr Member

    Trophy Points:
    77
    I am seeing progress on what you do, I am looking forward to seeing the finished product.

    PropReplicator2 likes this.
  14. samson1017

    samson1017 New Member

    Trophy Points:
    3
    Nice, excited to see the output. Keep up the good work.

    PropReplicator2 likes this.
  15. PropReplicator2

    PropReplicator2 Sr Member RPF PREMIUM MEMBER

    Trophy Points:
    1,731
    alexa0ne samson1017 thanks guys! Getting more electronics in the mail this week hopefully, and I should have a video up of the light system soon!

    Last edited by a moderator: Nov 8, 2018
  16. vader1974

    vader1974 Sr Member RPF PREMIUM MEMBER

    Trophy Points:
    1,560
    Looking forward to seeing what you use for the grebblies / bits / bobs.

    PropReplicator2 likes this.
  17. PropReplicator2

    PropReplicator2 Sr Member RPF PREMIUM MEMBER

    Trophy Points:
    1,731
    Thanks, most things will be custom sculpted, molded, and cast. Currently considering how I will make the button cover at the bottom.

  18. vader1974

    vader1974 Sr Member RPF PREMIUM MEMBER

    Trophy Points:
    1,560
    Yeah. I have been messing around with one of these. That bottom button looks brass, but surely it’s a rubber boot of some kind.

    PropReplicator2 likes this.
  19. vader1974

    vader1974 Sr Member RPF PREMIUM MEMBER

    Trophy Points:
    1,560
    Yeah. I think most replicas just stick with the original color of the plastic. We had a couple of episodes dedicated to the the Batzooka on “Talking Props”.

    https://youtu.be/L6EMsNaliU8

    https://youtu.be/03YR_yOUNnc

  20. Meule

    Meule Active Member

    Trophy Points:
    341
    Looking cool so far, can't wait to see your progress

    Hey, I've seen those episodes, nice to put a name to the face in this case :D
    And I guess I'll be going with a black Batzooka then

    vader1974 likes this.
  21. PropReplicator2

    PropReplicator2 Sr Member RPF PREMIUM MEMBER

    Trophy Points:
    1,731
    I’ve been messing around for the past few days with this and finished sculpting a custom boot for the push buttons I’m using. Since it looks like the cover is brass, I will try cold casting them in resin with some brass powder.

  22. PropReplicator2

    PropReplicator2 Sr Member RPF PREMIUM MEMBER

    Trophy Points:
    1,731
    Here is one after paint, and the brass screws holding the back plate on. Please note that in the first picture, there is a noticable "lump" of what looks like dripping paint. That's not what it is. The image exaggerates a small c-scar that I put in the sculpt to mimick peeling wood. It's definitely not that noticable in person.

  23. vader1974

    vader1974 Sr Member RPF PREMIUM MEMBER

    Trophy Points:
    1,560
    If you feel like I’m highjacking your thread let me know and I’ll delete my post.

    Here are my test parts with a quick paint job. I think the speaker holes need to be smaller.

  24. PropReplicator2

    PropReplicator2 Sr Member RPF PREMIUM MEMBER

    Trophy Points:
    1,731
    Alright, so instead of putting the button in the front, the brass piece will be static. This will allow me to make a more accurate button, and utilize the small carved out space in the lower portion of the radio for the button. The setup is a 9v battery and a momentary push button facing the bottom of the radio. It is glued into place so that it can't be pressed unintentionally, but it still easy to press. The bulb I chose lights up 15 feet of my hallway reasonably well too. Now to add the plexiglass!!

  25. PropReplicator2

    PropReplicator2 Sr Member RPF PREMIUM MEMBER

    Trophy Points:
    1,731
    Forgot to update this, but I finished the mouth portion, and have added antennas and am re-tweeting the brass circle.

  26. PropReplicator2

    PropReplicator2 Sr Member RPF PREMIUM MEMBER

    Trophy Points:
    1,731
  27. vader1974

    vader1974 Sr Member RPF PREMIUM MEMBER

    Trophy Points:
    1,560
    Lighting looks awesome. I worked on mine a bit more.


    Smaller holes on the speaker grill. I cut both wood and plexi grills and light cover border. Rub n Buff does not like the plexi (too smooth).

    PropReplicator2 likes this.
  28. vader1974

    vader1974 Sr Member RPF PREMIUM MEMBER

    Trophy Points:
    1,560
    How thick did yours end up being? My body is made of 1/4, 1/8, 1/4, and 1/4 layers with a 1/8 back cover. My wood detail parts are 1/8.

  29. PropReplicator2

    PropReplicator2 Sr Member RPF PREMIUM MEMBER

    Trophy Points:
    1,731
    My main body is 15/16” thick with a 1/8” thick backplate. The “smile” detail and speaker grill are both 1/8” as well. This seemed like the best balance between everything so it all remains proportionate.

    vader1974 likes this.
  30. PropReplicator2

    PropReplicator2 Sr Member RPF PREMIUM MEMBER

    Trophy Points:
    1,731
    Okay, so tonight is the night I return home after a short time away. I will take some images of a finished radio and post them tonight as I can. After 8 attempts at different grills I have finally landed on cold casting them all with bronze powder and hand drilling every hole on the grills. It takes a little more time, but the finished product looks absolutely spot on, so this is what will be done.

  31. PropReplicator2

    PropReplicator2 Sr Member RPF PREMIUM MEMBER

    Trophy Points:
    1,731
    Finished my prototype tonight.. the chrome bearings on the antennas are just for proof of concept and will be replaced with the accurate antenna-setup for the ones produced in my run.

    vader1974 likes this.
