1/18 Firefox

Discussion in 'General Modeling' started by IEDBOUNTYHUNTER, Jun 10, 2015.

  1. IEDBOUNTYHUNTER

    IEDBOUNTYHUNTER Sr Member

    Trophy Points:
    1,355
    I posted this here because i wasnt sure if the filming mini was exactly this size. I think it was a little bigger. So 1/18 works out to be 42 inches long. Hopefully we can get this into Kit form soon. Special Thanks to a few good friends who are helping out with the Printing and files. No names at this point not sure if they want any credit yet. But the STl is being worked on. and should have some parts soon. Good to see this getting done. Finally, ive wanted one since way back when i did my X jet.

    Heres a few pics of the file. Color indicates parts breakdown. This is just a quick render. not all parts may be printed. Might get a few photo etched. still working on the details.

    Al

    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]

    Wes R and 32buds like this.
  2. 32buds

    32buds Well-Known Member

    Trophy Points:
    537
    That is my all time favourite movie aircraft! Will it be downloadable, or will you be selling sections through a 3d printshop , like shapeways?

    TheNylonGag likes this.
  3. IEDBOUNTYHUNTER

    IEDBOUNTYHUNTER Sr Member

    Trophy Points:
    1,355
    Still Discussing whats going to happen. It will probably be kitted. But i know i want a Fiberglass Version. might make available a resin cast version. I will let you know as it gets closer to molding.

    Al

    32buds likes this.
  4. 32buds

    32buds Well-Known Member

    Trophy Points:
    537
    Good stuff. I've already subscribed to this thread!:)

  5. Martin-El

    Martin-El Well-Known Member

    Trophy Points:
    941
    Very impressive -
    42" long...! I imagine it will be expensive in the extreme..?

  6. IEDBOUNTYHUNTER

    IEDBOUNTYHUNTER Sr Member

    Trophy Points:
    1,355
    Thats why i would recommend the fiberglass version. Alot cheaper to produce. Resin is alot more expensive. But were hoping to sell some. So it wont break the bank account.

    32buds likes this.
  7. TheNylonGag

    TheNylonGag Well-Known Member Gone but not forgotten.

    Trophy Points:
    935
    You know Al

    I thought we were mates

    I'm doing my thing, you helped me, you inspire me


    AND then

    Firefox

    BANG

    My favourite

    42"

    how am i supposed to finish my stuff with you flaunting your perfect stuff, an giggling it in my face
    i've always wanted this plane big and in my life

    !/.12 baby

    Gag

    Just beautiful my friend

    PS

    MY FRIGGIN BOOK

  8. Martin-El

    Martin-El Well-Known Member

    Trophy Points:
    941
    This is good news!!

    32buds likes this.
  9. JPCOdessa70

    JPCOdessa70 Active Member

    Trophy Points:
    262
    Very very much interested!

    My dream is to make a diorama of the following scene.. where Clint is about to board the Mig 31....and the 2nd prototype is in the background...YES!! Very much LIKE!!!

    Mig31Firefox1982.jpg PrevueloClint1-450x206.jpg

    Opps...it is 1/18 scale very BIG I guess for a diorama...but it is cool to think of the possibilities....

  10. IEDBOUNTYHUNTER

    IEDBOUNTYHUNTER Sr Member

    Trophy Points:
    1,355
    Thanks guys.

    Gag. Lol. You dont need the book. Your doing fine. I will PM you about the Firefox

  11. 3d-builder

    3d-builder Sr Member

    Trophy Points:
    1,355
    Project is in good hands.......I remember the x-jet....:thumbsup

  12. Strode

    Strode Well-Known Member

    Trophy Points:
    866
    Can't wait to see you build this!

  13. Galane

    Galane New Member

    Trophy Points:
    17
    This is going to be soooo nice! Won't have to think in Russian to build it. ;-)

  14. Martin-El

    Martin-El Well-Known Member

    Trophy Points:
    941
    Is there any danger of this being made in other (smaller) scales too I wonder..?

    32buds likes this.
  15. 32buds

    32buds Well-Known Member

    Trophy Points:
    537
    1/32 or 1/48 would be perfect, but lets wait and see what the modelling genius comes up with!

  16. IEDBOUNTYHUNTER

    IEDBOUNTYHUNTER Sr Member

    Trophy Points:
    1,355
    No genius here, just like to make things. Not sure about a smaller one yet. Once this one gets done. If theres enough interest maybe will do a smaller version. The file can be scaled to any size. Possibly after the four foot X wing and sand skiff im working on.

    32buds likes this.
  17. rbeach84

    rbeach84 Sr Member

    Trophy Points:
    1,406
    Might someone outline the basic process that arrives at fiberglass 'kit' parts? My conceptual block is what to (efficiently) make the master from and then translate it into fiberglass tooling. I don't have access to CNC or CAD resources myself, other than 2D AutoCAD, so I am forced to carve it essentially by hand (old school) Would like to use cheap building foam sheet but haven't yet found a decent bonding agent for gluing up the profile blocks...

    Regards, Robert

  18. IEDBOUNTYHUNTER

    IEDBOUNTYHUNTER Sr Member

    Trophy Points:
    1,355
    If you look at my profile. Under threads. Look for X jet. Theres a pretty good breakdown of pattern to finshed fiberglass part.

    To glue the foam together i use 5 minute epoxy. The trick is to use the glue as far in as possible. You dont want to be carving the foam and hit glue. Doesnt always work that way. But i try. Its a pain to sand the glue. If i hit a spot i usually chip it out and fill with bondo

  19. rbeach84

    rbeach84 Sr Member

    Trophy Points:
    1,406
    Thanks for the tip, IED-BH. Great job on the X-Men jet, eh. Looks like you were using some grade of modeling foam, probably works better than construction panel...

    Regards, Robert

  20. IEDBOUNTYHUNTER

    IEDBOUNTYHUNTER Sr Member

    Trophy Points:
    1,355
    Robert, Doesnt matter what you use as long as your building. As for the Fire fox. Parts will be hitting the printer Very soon. of course i will post pics and construction as i go.

    Al

    32buds and TheNylonGag like this.
  21. IEDBOUNTYHUNTER

    IEDBOUNTYHUNTER Sr Member

    Trophy Points:
    1,355
    Alright. got some pics of the first parts to be printed. should be finished printing by next week. then i will clean up all the parts and test fit. then primer adjust anything that needs it. theres always clean up no matter how good the print is. once all thats done we will decide on how we want to mold it .

    The panel lines are cut deep to help when we add the primer so they dont get lost.

    Thanks for looking.

    Al

    [​IMG]
    [​IMG]
    [​IMG]

    32buds likes this.
  22. rbeach84

    rbeach84 Sr Member

    Trophy Points:
    1,406
    Too cool! BTW, what scale (sorry if you already said...)
    Regards, Robert

  23. IEDBOUNTYHUNTER

    IEDBOUNTYHUNTER Sr Member

    Trophy Points:
    1,355
    1/18. 42 inches long

  24. rbeach84

    rbeach84 Sr Member

    Trophy Points:
    1,406
    Sorry, I knew that.. well, I was thinking something smaller looking one of the images of the printed parts in your hand. Fooled myself!
    Regards, Robert

  25. IEDBOUNTYHUNTER

    IEDBOUNTYHUNTER Sr Member

    Trophy Points:
    1,355
    Yeah. its hard to tell scale looking at those pics. the model was chopped into a few parts for ease of printing.

  26. Nwerke

    Nwerke Master Member

    Trophy Points:
    3,810
    Blimey, this looks good - great work! Suddenly an embarrassment of Firefox riches but there can't be too many after all these years. :thumbsup

  27. IEDBOUNTYHUNTER

    IEDBOUNTYHUNTER Sr Member

    Trophy Points:
    1,355
    YES, to long has the world waited for this... we are making it happen this summer. parts should be dont this week. then i will get to prepping them for molding.


    LOL.

  28. Nwerke

    Nwerke Master Member

    Trophy Points:
    3,810
    At this scale you should seriously give some thought to doing lightweight epoxy-glass castings. Dual market - I think you'd find the model can be adapted to EDF RC. :D

  29. IEDBOUNTYHUNTER

    IEDBOUNTYHUNTER Sr Member

    Trophy Points:
    1,355
    Thats all i ever do. Not a fan of solid resin parts. I only use resin for detail parts. Check out my X jet. All epoxy fiberglass. Only way to make it.

    Nwerke likes this.
  30. Nwerke

    Nwerke Master Member

    Trophy Points:
    3,810
    D'oh, haha! Brilliant.

  31. IEDBOUNTYHUNTER

    IEDBOUNTYHUNTER Sr Member

    Trophy Points:
    1,355
    Fresh off the printer. oops soon to be off the printer,

    [​IMG]


    more soon.

    32buds and Randy13 like this.
  32. Nwerke

    Nwerke Master Member

    Trophy Points:
    3,810
    Hoo! What print tech is this? Looks pretty decent.

  33. IEDBOUNTYHUNTER

    IEDBOUNTYHUNTER Sr Member

    Trophy Points:
    1,355
    The parts look even better cleaned up. All i know is the Printer is close to $500.000.00

  34. Nwerke

    Nwerke Master Member

    Trophy Points:
    3,810
    Yeah, figures. They really shouldn't cost that much; there's some patent-trolling going on in that sector, or so I'm told. But at least it is driving a lot of innovation; home units which can do parts this nice - at speed and a sane price - are on the horizon. Congrats on the 3D model btw, that's some accurate-looking work.

    32buds likes this.
  35. IEDBOUNTYHUNTER

    IEDBOUNTYHUNTER Sr Member

    Trophy Points:
    1,355
    I cant take credit for the 3-d model. Thats the work of a guy who has been researching firefox for many years.

    Im just handling the build part of this

  36. jockdeboer

    jockdeboer Well-Known Member RPF PREMIUM MEMBER

    Trophy Points:
    666
    If you are making a list, put me on it.

  37. IEDBOUNTYHUNTER

    IEDBOUNTYHUNTER Sr Member

    Trophy Points:
    1,355
    We got big parts.

    [​IMG]

    32buds likes this.
  38. crackerjazz

    crackerjazz Sr Member

    Trophy Points:
    1,525
    Wow -- that's one huge model! Technology meets classic model-building! Looking forward to your updates.

  39. Nwerke

    Nwerke Master Member

    Trophy Points:
    3,810
    Yeah, I realise you would have specified if the CG was your own work. Pass on my congrats? I know an accurate 'fox when I see one, and there haven't been many. :p

    Oh hell, now I have that big butts song stuck in my head. :lol That is one sexy (and huge) rear end. :lol

  40. 32buds

    32buds Well-Known Member

    Trophy Points:
    537
    WOW, and WOW again. That looks amazing. Can't wait to see the finished article!

  41. IEDBOUNTYHUNTER

    IEDBOUNTYHUNTER Sr Member

    Trophy Points:
    1,355
    Will says thank you on the firefox accuracy. He worked for years to get it correct. The nose is perfect. He nailed it perfectly.

    Me and will are getting glass versions of this. Any one interested in one can PM. Not starting a FS thread yet to early

    32buds likes this.
  42. rbeach84

    rbeach84 Sr Member

    Trophy Points:
    1,406
    IBH, any chance Will might make some 4-views with x-sections available? I'd like to make one in 1:48 scale using hand techniques for the master (probably would go the vac-formed shell route... old school, I know!)

    Regards, Robert

  43. Clutch

    Clutch Master Member

    Trophy Points:
    3,336
    Wow. Wish it wasn't so big. But it is gonna be killer.

  44. Army

    Army New Member

    Trophy Points:
    16
    This is gonna be killer!! I must have!!

  45. IEDBOUNTYHUNTER

    IEDBOUNTYHUNTER Sr Member

    Trophy Points:
    1,355

    I will ask him. but not sure.

    All the large parts have been shipped to me. should have them in a few days. heres a few more pics of the parts. All the detail is there. once i get them i will shoot some primer on them so the panel lines and details will stand out better.

    [​IMG]
    [​IMG]
    [​IMG]

  46. Keith

    Keith Sr Member

    Trophy Points:
    1,730
    Me want!

    Keith.

  47. theprofessor

    theprofessor Active Member

    Trophy Points:
    360
    Oh, that's friggin' AWESOME! Beautiful parts there.

  48. rbeach84

    rbeach84 Sr Member

    Trophy Points:
    1,406
    Thanks, IBH. Very exciting project... R/ Robert

  49. TheNylonGag

    TheNylonGag Well-Known Member Gone but not forgotten.

    Trophy Points:
    935
    Stunning Mate

  50. Nwerke

    Nwerke Master Member

    Trophy Points:
    3,810
    Oh it's glorious. And it's Will's - of course it is! Say no more. I hope he's doing better these days. :thumbsup
